Brand - DODGE
Item Number - DODGE - P2B510-ISAF-045MRE
Category - IMPERIAL ISAF 2-Bolt with Trident Seal (Expansion)
Type - Push-Pull Adapter
Bearing - 22210
Shaft Size (mm) - 45
Part Name - P2B510-ISAF-045MRE
SAF Series - 510
Length Through Bore (A) mm - 71.12
Overall Length (B) mm - 209.55
Width (C) mm - 60.45
Bolt to Bolt Minimum Distance (D min) mm - 165.1
Bolt to Bolt Maximum Distance (D max) mm - 177.8
F-Bolt Diameter - M12
G (mm) - 22.35
H (mm) - 26.16
Overall Height (J) mm - 138.43
L (mm) - 76.2
Base to Center Height (M) mm - 63.5
P (mm) - 147.57
S (mm) - 43.94
Expansion (X) mm - 5.56
Y (mm) - 0.51
Z (mm) - 52.83
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow Block 2 Bolt Base
5XX - for interchangeable SAF style housings
ISAF - IMPERIAL SAF
M - Metric
R - TRIDENT Triple Lip Contact Seal
E - Expansion

** Images are representation purposes only
