Brand - DODGE
Item Number - 070422 DODGE - P4B-S2-215LE
Category - 4-Bolt Base S-2000 Pillow Block in Labyrinth Seal (Expansion)
Bearing Series - 22215
Shaft Size (inch) - 2.9375
Part Name - P4B-S2-215LE
Length Through Bore (A) inch - 3.59
Overall Length (B) inch - 10.44
Width (C) inch - 3.75
Bolt to Bolt Minimum Distance (D min) inch - 7.94
Bolt to Bolt Maximum Distance (D max) inch - 8.31
E (inch) - 1.88
F-Bolt Diameter (inch) - 0.625
G (inch) - 0.94
H (inch) - 1.88
Overall Height (J) inch - 6.44
L (inch) - 4.7
Base to Center Height (M) inch - 3.25
S (inch) - 2.5
Total Expansion (X) inch - 0.25
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P4B - Pillow Block 4-Bolt Base, Cast Iron
S2 - S2000
L - Labyrinth Metallic Seal
E - Expansion Type Bearing

** Images are for representation purposes only
